IP-SIP Security Panphone

Posted: March 21, 2022

Anti-Vandalic Security IP-SIP intercom with CSIP Card

Anti-vandal Security intercom for IP-SIP standard extension, with quality audio and full duplex communication, high resistance and durability with piezoelectric Call button, for outdoor or indoor use.

It is the Panphone anti-vandal security version, with a completely flat surface without holes, for specific security applications or applications that do not require a camera or card reader in the same device.

It allows automatic dialing to an IP-SIP PBX’s extension by touching the piezoelectric call button.

The IP Security Panphone are fully POE with enhanced audio characteristics like: high-quality audio, full duplex communication, echo canceller, ambient noise reduction, and more.

It allows up to 5 independent SIP accounts and it is possible to select among multiple codecs (g.722, g.726, g.729, g.711a/u, GSM and OPUS that allows bandwidth adjustment).

It is possible to activate the relay by code dialing from a remote extension or by external devices for which schedules and times can be set.

It also includes the ability to connect to external devices (biometric readers, proximity, etc.) and manage I/O inputs and outputs for LEDs, Indicators and other devices, with the option of adding more digital inputs and extra relay output with OPTO card.

Thanks to its IP-55 casing and its installation versatility, they can be used outdoors and in hygienic environments that require constant cleaning.

It is perfect for security applications among other access applications, for example, exterior doors for buildings or houses, prisons, multiple office locations or doors, garages and hospital environments (see common uses).

Additionally, it facilitates maintenance work since it allows remote management and testing with public IP or through VPN.

They can be integrated with other external platforms through connection to databases, communication protocols and/or remote management or through APIs for special projects.

FeaturesProduct VersionsCommon uses

General features:

Handsfree intercom with hanging and automatic hang-up
Flat surface without holes for flush mounting
A piezo-electric call button
Direct Connection to IP SIP of PBX centrales IP with SIP standard.
Up to 5 independent IP-SIP accounts.
Improved audio quality, Full Duplex audio, Echo Canceller and Ambient Noise Reduction.
Codecs: g.722, g.726, g.729, g.711a/u, GSM and OPUS.
Call status audio messages (Door open, call in progress, close door, among others) in Spanish and English
Remote administration via web interface.
Plate with 2 independent dry contact relays. Ideal for doors that activate electrically or external devices (card readers, fingerprint, etc).
Opening doors remotely (activation of relays) with dailing code from any extension.
Door opening/relay activation locally by PIN code dialing (with external version), RFID (with external reader) and QR code (with external camera).
Programming of relay activation times and periods for PIN numeric codes, RFID and QR
Up to 250 users for PIN, RFID or QR.
Supports Video Call and Video Streaming with camera version.
IP-55 Resistant anti-vandal case for indoor or outdoor for environmental and hygenic conditions.
Wiring required, UTP and AC Power in cases of non-POE installation.
Winegard ports for other devices (biometrics, readers, etc.)
LED ports for indicators.
TLS Coding
DHCP support
RS-485, MODBUS (Scada) protocols support
Administration, local and remote configuration via web interface and SMNP, either by Public IP or via VPN
Remote audio test (speaker and mic).
Traffic Log Management and accesses, exportable to .xls, .csv and .pdf.
Option for Additional OPTO card with 4 digital inputs and 1 relay output.
Option for integration with third party APIs or external DDBB.
Option for event notification via SIP call.
It works with Centrals (PBX) with Asterisk IP software and power stations such as Alcaltel, Avaya, Cisco, Elastix, Epygi, Denwa, Matrix, Nec, Panasonic, Siemens, Hiper PBX, Xorcom, Yeastar and Zycoo, and others.

*Note: visit ‘ product’s versions’ to check references.

IP-SIP Security Panphone

Reference	5530
Format	Flush Mount
Button or piezo-electric Keyboard	1 button
Dimensions (HxWxD) mm	External 217,41×128,8×8,6 Interior 180×91,40×30
Camera	No
Card Reader	No

Penitentiary Centers.
Centralized access control for multiple sites or doors.
Unattended gatehouses or guardhouses.
Hospital environment, accesses, operating
rooms, etc.
Assistance zones in buildings and hotels.
Parking barriers and Tollgates.
Evelators
Roadside Emergency Callers (SOS points)
Public transportation stations
Gas stations, unattended service stations
HealthCare and geriatric environments.
Accessibility systems for reduced mobility people.
Vending machines
Public address system

Datasheet ENG

WIFI Security Panphone

Posted: March 21, 2022

Anti-Vandalic Security WIFI intercom with CSIP Card

Anti-vandal and Security WIFI intercom for IP-SIP standard extension, with quality audio and full duplex communication, high resistance and durability with piezoelectric Call button, for outdoor or indoor use.

It is the Panphone anti-vandal security version, with a completely flat surface without holes, for specific security applications or applications that do not require a camera or card reader in the same device. With WIFI functionality to facilitate installation in places that are difficult to access with conventional wiring.

It allows automatic dialing to an IP-SIP PBX’s extension by touching the piezoelectric call button.

It has enhanced audio features like full duplex audio communication, echo canceller, ambient noise reduction, and more. It allows up to 5 independent SIP accounts and it is possible to select among multiple codecs (g.722, g.726, g.711, GSM and OPUS that allows bandwidth adjustment).

It also includes the ability to connect to external devices (biometric readers, proximity, etc.) and manage I/O inputs and outputs for LEDs, Indicators and other devices, with the option of adding more digital inputs and extra relay output with OPTO card.

Thanks to its IP-55 casing and its installation versatility, they can be used outdoors and in hygienic environments that require constant cleaning at any point with Wi-Fi network coverage. Its approximate wireless range is 100 meters in open spaces and 50 in closed spaces.

It is perfect for security applications among other access applications, for example, exterior doors for buildings or houses, prisons, multiple office locations or doors, garages and hospital environments (see common uses).

Additionally, it allows remote management and testing facilitating maintenance work.

It is possible its integration with other platforms through APIs as an option, ideal for special projects.

FeaturesProduct VersionsCommon uses

General features:

Handsfree intercom with hanging and automatic hang-up
Flat surface without holes for flush mounting
A piezo-electric call button
Direct Connection to IP SIP of PBX centrales IP with SIP standard via WIFI.
Up to 5 independent IP-SIP accounts.
Improved audio quality, Full Duplex audio, Echo Canceller and Ambient Noise Reduction.
Codecs: OPUS; g722, g726, g711 and GSM.
WIFI IEE 802.11 b,g,n, at 2,4 GHz/300Mbps
Call status audio messages (Door open, call in progress, close door, among others)
Remote administration via web interface.
Plate with 2 independent dry contact relays. Ideal for doors that activate electrically or external devices (card readers, fingerprint, etc).
Opening doors remotely (activation of relays) with dailing code from any extension.
IP-55 Resistant anti-vandal case for indoor or outdoor for environmental and hygenic conditions.
Approximate wireless range of 100 meters in open spaces and 50 in closed spaces.
Power only wiring.
Winegard ports for other devices (biometrics, readers, etc.)
LED ports for indicators.
Remote audio test (speaker and mic)
Call traffic logs.
Option for Additional OPTO card with 4 digital inputs and 1 relay output.
Option for integration with third party APIs.
Option for event notification via SIP call.
It works with Centrals (PBX) with Asterisk IP software and power stations such as Alcaltel, Avaya, Cisco, Elastix, Epygi, Denwa, Matrix, Nec, Panasonic, Siemens, Hiper PBX, Xorcom, Yeastar and Zycoo, and others.

*Note: visit ‘ product’s versions’ to check references.

WIFI Security Panphone

Reference	5534
Format	Flush Mount
Button or piezo-electric Keyboard	1 button
Dimensions (HxWxD) mm	External 217,41×128,8×8,6 Interior 180×91,40×30
Camera	No
Card Reader	No

Penitentiary Centers.
Centralized access control for multiple sites or doors.
Unattended gatehouses or guardhouses.
Hospital environment, accesses, operating
rooms, etc.
Assistance zones in buildings and hotels.
Parking barriers and Tollgates.
Evelators
Roadside Emergency Callers (SOS points)
Public transportation stations
Gas stations, unattended service stations
HealthCare and geriatric environments.
Accessibility systems for reduced mobility people.
Vending machines
Public address system

Analog Security Panphone

Posted: March 21, 2022

Anti-Vandalic Analog Security intercom

Anti-vandal Security intercom for standard Analog extension, high resistance and durability with piezoelectric with piezoelectric Call button, for outdoor or indoor use.

It is the Panphone anti-vandal security version, with a completely flat surface without holes, for specific security applications or applications that do not require a camera or card reader in the same device.

It allows automatic dialing to PBX standard extension by touching the piezoelectric call button.

It has 2 dry contact relays that work independently, for electric door’s connection, which can be activated from remote extension. It can also be activated from external devices (such as card readers, biometric, proximity, etc.), since it has digital inputs to which buttons and sensors can also be connected.

Thanks to its IP-55 casing and its installation versatility, they can be used outdoors and in hygienic environments that require constant cleaning.

It is perfect for security applications among other access applications, for example, exterior doors for buildings or houses, prisons, multiple office locations or doors, garages and hospital environments (see common uses).

FeaturesProduct VersionsCommon uses

General features:

Handsfree intercom with hanging and automatic hang-up
Flat surface without holes for flush mounting
A piezo-electric call button
Direct Connection to analog of PBX EXT standard
With 2 independent dry contact relays. Ideal for doors that activate electrically or external devices (card readers, fingerprint, etc).
Opening doors remotely (activation of relays) with dailing code from any extension.
Anti-vandalism IP-55, for indoor or outdoor for hygienic environments or environmental conditions.
Wiring, needs 2 wires and AC power, in case a version with camera, so add 1 UTP
It works with all PBX that has a conventional analog EXT.

*Note: visit ‘ product’s versions’ to check references.

Analog Security Panphone

Reference	5030
Format	Flush Mount
Button or piezo-electric Keyboard	1 button
Dimensions (HxWxD) mm	External 217,41×128,8×8,6 Interior 180×91,40×30
Camera	No
Card Reader	No

Centralized access control for different sites or doors.
For attended or unattended gateways
Care and geriatric environments.
Parking and tolls
Gas stations, unattended service stations
For evelators
Emergency intercom on the high way (SOS points)
Public transportation stations
Accessibility systems for reduced mobility people.
Intercom in prisons
For specific areas or emergency in hotels, hospitals and other types of builidng
Vending machines
Intercoms for operating rooms and hospitals, etc.
Public address system

GSM Security Panphone

Posted: March 21, 2022

Anti-Vandalic Security GSM intercom

Anti-vandal and Security intercom for Mobile Cellular line, high strength and durability with with piezoelectric Call button, for outdoor or indoor use.

It is the Panphone anti-vandal security version, with a completely flat surface without holes, for specific security applications or applications that do not require a camera or card reader in the same device.

It is ideal for establishments where wiring is not possible or required (voice or data), allowing greater versatility and fast in installation.

Dialing automatic to a phone number by pressing the button through the cellular mobile network. It can be used as an intercom and as a remote access control.

It allows dialing up to 10 pre-configured numbers that are dialed sequentially in case there is an error in the call or no answer.

It has 2 dry contact relays that operate independently, for connection of electric doors, which can be activated from remote telephone (with code, SMS or missed call). It can also be activated from external devices (such as card readers, biometric, proximity, etc.), since it has digital inputs to which buttons and sensors can also be connected. It can generate alarms by calling a telephone number with the activation of some sensor input.

Now GSM intercoms can have pre-recorded messages that indicate the status or activity. These messages can be in several languages, Spanish (Spanish), English, Portuguese and Catalan, are available, other languages upon request.

Thanks to its IP-55 housing, it can be used outdoors in places inhospitable and in hygienic environments that require constant cleaning.

It is perfect for security applications among other access applications, for example, exterior doors for buildings or houses, prisons, multiple office locations or doors, garages and hospital environments (see common uses).

FeaturesProduct VersionsCommon uses

General features:

Handsfree intercom with hanging and automatic hang-up
Flat surface without holes for flush mounting
A piezo-electric call button
Direct connection via telephone by Cellular Mobile Line.
Sequence dialing to 10 programmed numbers.
With 2 independent dry contact relays. Ideal for doors that activate electrically or external devices (card readers, fingerprint, etc).
Opening doors remotely (activation of relays) with dailing code from any telephone or by making a call or SMS
IP-55 Resistant anti-vandal case for indoor or outdoor for environmental and hygenic conditions.
Contact input (sensors, alarms, etc.) to make a call.
Wiring, AC power

It works with the most common mobile cellular network frequencies (850, 900, 1800 and 1900 Mhz), which allows its use in coverage areas of different networks.

*Note: Note, visit ‘ product’s versions’ to check references.

GSM Security Panphone

Reference	5330
Format	Flush Mount
Button or piezo-electric Keyboard	1 button
Dimensions (HxWxD) mm	External 217,41×128,8×8,6 Interior 180×91,40×30
Camera	No
Card Reader	No

Control de acceso para distintas sedes o puertas.
Garitas o porterías remotas desatendidas.
Sedes remotas y de difícil acceso.
Barreras de parking y peajes.
Gasolineras, estaciones de servicio desatendidas.
Garajes.
Ascensores.
Comunicadores de emergencia en carreteras (puntos SOS).
Estaciones de transporte publico.
Sistemas de accesibilidad para personas de movilidad reducida.
Zonas Refugio o de Emergencia en hoteles, hospitales y otro tipo de edificaciones.
Maquinas de vending.
